ADJ PIXIE DRIVER 8000 Control for Pixie Strip
- £1,041.00
- £1,041.00
- Unit price
- per
Pixie Driver 8000 is designed specifically for the ADJ Pixie Strip 30, Pixie Strip 60, and Pixie Strip 120.
iFrame
Description:
Pixie Driver 8000 is designed specifically for the ADJ Pixie Strip 30, Pixie Strip 60, and Pixie Strip 120. It provides easy and versatile control options including simple on-board manual dimming and strobe control, plus full pixel mapping control of 8,160 max pixels via Kling-Net, 1,360 max pixels via Art-Net or sACN (streaming ACN) protocols.
The Pixie Driver 8000 features a universal auto switching power supply (100-240V), a 4-button LCD control menu display, RJ45 Ethernet in/out ports, (8) Pixie Strip outputs which use proprietary, 4-pin combo cables (sold separately) that supply power and data to each pixie strip (available in lengths from 30cm to 15m (For additional details, see Accessories Sold Separately under the Specifications section). The Pixie Driver 8000 can be mounted in a standard 19-inch rack (rack ears included) or attached to truss with a clamp (not included).
Specifications:
Control Features:
Power / data supply for ADJ Pixie Strip 30, Pixie Strip 60, and Pixie Strip 120
Manual RGB mode
Internal programs
Manual Dimming and Strobe Control
Full Pixel Mapping Control
Drives up to 8,160 Pixels via KlingNet (1,020 Pixels per port)
Drives up to 1,360 Pixels via Art-Net and sACN (170 Pixels per port)
OLED screen with 4-button menu
USB port for Firmware Updates
Control Features:
Power / data supply for ADJ Pixie Strip 30, Pixie Strip 60, and Pixie Strip 120
Manual RGB mode
Internal programs
Manual Dimming and Strobe Control
Full Pixel Mapping Control
Drives up to 8,160 Pixels via KlingNet (1,020 Pixels per port)
Drives up to 1,360 Pixels via Art-Net and sACN (170 Pixels per port)
OLED screen with 4-button menu
USB port for Firmware Updates
Control Quantity:
KlingNet: (34) Pixie Strip 30's, (17) Pixie Strip 60's or (8) Pixie Strip 120's (Per port. Or any combination not exceeding 1,020 pixel per port)
ArtNet: (5) Pixie Strip 30's, (2) Pixie Strip 60's or (1) Pixie Strip 120 (Per port. Or any combination not exceeding 170 pixel per port)
sACN: (5) Pixie Strip 30's, (2) Pixie Strip 60's or (1) Pixie Strip 120 (Per port. Or any combination not exceeding 170 pixel per port)
Connections:
Locking Power Input
Two KlingNet / Artnet ethernet ports
Eight 4-pin DC24V power/data outputs to Pixie Strips
Mounting Options:
Bolt to add a clamp to hang from truss (clamp and truss not included)
Includes 19-inch rack mount ears
Safety eye
Electrical:
Multi-voltage operation: AC 100-240V, 50/60Hz
Power Consumption: 1,600W max
-20°C to 45°C
Dimensions / Weight:
Dimensions (LxWxH): 294x480x120mm
Weight: 6.5 kg.
Approvals:
CE | cETLus (Pending)
Included Accessories:
(1) PSLC10: 3m, 4-pin cable. Connects between Pixie Driver 8000 and Pixie Strip.
(1) Power Input cable
(2) 19" Rack Ears
