Chauvet Professional COLORado Expo W PAR 117W 3200K Warm White LED (IP65 rated)

Description:

COLORado Expo W is a rugged IP65-rated indoor/outdoor wash light that projects over 5,000 lumens of extremely high quality 3200K warm white light with a 12° beam angle. High-resolution 16-bit dimming is perfectly smooth and manually adjusting output is intuitively easy with its onboard rotary dimming dial. Phenomenal CRI and TLCI scores, selectable PWM, and included gel accessories make the COLORado Expo W a versatile instrument, on-site or on camera, in any setting.

Features:

IP65-Rated
Indoor / outdoor wash light
Projects over 5,000 lumens
3200K Warm light
12-Degree beam angle
16-Bit rotary dimming dial
CRI and TLCI scores
Selectable PWM

Specifications:

Optical
Light Source: 1 LED (WW) 117 W, (2.187 mA), 3283 K 50,000 hours life expectancy.
Color Temperature (at full): 3283
CRI: 97.9
TLCI: 98
Beam Angle: 12.7°
Field Angle: 23.4°
Lumens : 5237
Illuminance (49°): 254 lux @ 5 m
Illuminance (total) : 2403 lux @ 5 m
Selectable PWM: 600Hz, 1200Hz, 2000Hz, 2400Hz, 6000Hz, 18,000 Hz
Dynamic Effects
Dimmer: Electronic
Shutter/Strobe: Electronic
Strobe Rate: 0 to 25Hz
Dim Modes: 4
Built-in Automated Programs: Yes
Construction / Physical
Dimensions: 11.42 x 9 x 15.83 in (290 x 228 x 402 mm)
Weight: 16.4 lb (7.4 kg)
Exterior Color: Black
Housing Material: Magnesium alloy
Accessory Holder/Gel Frame Size: 7.5 in (190 mm)
Connections
Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
Power Input: Seetronic Powerkon IP65
Power Output: Seetronic Powerkon IP65
Data Connectors: 5-pin XLR
Cable Length (power): 5 ft (1.5 m)
Control
Control Protocol: DMX, RDM
DMX Channels: 1, 2, 3 or 4
Modes/Personalities: 4 personalities (1ch, 2ch, 3ch, 4ch)
Electrical
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 8 units @ 100 V; 9 units @ 120 V; 16 units @ 208 V; 18 units @ 230 V; 18 units @ 240 V
Power and Current: 150 W, 1.495 A @ 100 V, 60 Hz [9.6 A inrush]
Power and Current: 149 W, 1.234 A @ 120 V, 60 Hz [7.4 A inrush]
Power and Current: 145 W, 0.723 A @ 208 V, 60 Hz [6.4 A inrush]
Power and Current: 145 W, 0.657A @ 230 V, 50 Hz [6.8 A inrush]
Power and Current: 145 W, 0.633 A @ 240 V, 50 Hz [7.0 A inrush]
Power and Current (resting): 7 W, 0.100 A @ 100 V, 60 Hz
Power and Current (resting): 7 W, 0.098 A @ 120 V, 60 Hz
Power and Current (resting): 6 W, 0.115 A @ 208 V, 60 Hz
Power and Current (resting): 6 W, 0.121 A @ 230 V, 50 Hz
Power and Current (resting): 6 W, 0.125 A @ 240 V, 50 Hz
Certifications / Qualifications
CE, MET, FCC, ETL, cULus, UKCA
IP Rating: IP65, outdoor/wet, with pressure equalizing M12 GORE valve
