Chauvet Professional Ovation P-56VW Compact LED PAR-Style Fixture Variable White 48x4W

Description:

Ovation P-56VW is a bright, compact, and virtually silent par with exceptionally high CRI that is ideal for theatrical and studio applications. The sleek, modern-style par produces a homogenized, single-source, flat and even field of light with the same efficient warm white LED system found in the award-winning Ovation E-260WW ellipsoidal. Interchangeable lens plates are included for medium and wide beam angles. The virtually silent par also features extremely smooth 16-bit dimming, as well as RDM and PWM for set-up ease.

The unit accepts standard 7.5” beam shaping accessories.

Features:

Variable white PAR-style fixture with homogenized single source of light
Interchangeable lens plates included for medium and wide beam angles
Soft, even field of light
Quiet operation for use in any situation with fan speed control
+/- Green adjustment via DMX or on-board control
Independent color control over the 6-color engine when a splash of color is needed
RDM and variable Pulse Width Modulation for setup ease
Accepts standard 7.5” beam shaping accessories
16-bit dimming resolution for smooth fades

Specifications:

General
OPTICAL Light Source: 48 LEDs (6 red, 6 green, 10 blue, 4 R. blue, 6 orange, 16 lime) 3 to 4 W, (1 A), 50,000 hours life expectancy
Color Temperature (range): 2800 to 8000 K
CRI: 92-93
Illuminance (Medium Lens): 1220 lux @ 5 m
Illuminance (Wide Lens): 220 lux @ 5 m
Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4000 Hz, 6,000 Hz, 25000 Hz
DYNAMIC EFFECTSDimmer: Electronic
Shutter/Strobe: Electronic
Strobe Rate: 0 to 29 Hz
Standalone Color Mixing: Yes
Color Temperature Presets: Yes
Dim Modes: 4
Built-in Automated Programs: Yes
CONNECTIONSPower Connection: Edison (Local) plug to Neutrik powerCON
Data Connectors: 3- and 5-pin XLR
Cable Length (power): 5 ft (1.5 m)
CONTROLControl Protocol: DMX, RDM
DMX Channels: 3, 5, 6, 8, 11, 15 or 17
Modes/Personalities: 7 personalities (3, 5, 6, 8, 11, 15, 17)
ELECTRICALInput Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 11 units @ 120 V; 18 units @ 208 V; 20 units @ 230 V
Power and Current: 150 W, 1.22 A @ 120 V, 60 Hz
Power and Current: 155 W, 0.70 A @ 208 V, 60 Hz
Power and Current: 158 W, 0.66 A @ 230 V, 50 Hz
Physical & Dimensions
Height: 317mm
Width: 326mm
Depth: 363mm
Weight: 5.5kg
Exterior Color: Black
Accessory Holder/Gel Frame Size: 7.5 in (191 mm)
