db technologies DVA-KS20 2x 18" 4000W Subwoofer
- £2,974.00
- £2,974.00
- Unit price
- per
Featuring a double 18" woofer pairing in a bass reflex housing, the DVA KS20 is equipped with 2x Digipro G3 Power Amplifiers delivering 4000 W Peak.
iFrame
Description:
Featuring a double 18" woofer pairing in a bass reflex housing, the DVA KS20 is equipped with 2x Digipro G3 Power Amplifiers delivering 4000 W Peak. The system's internal design brings together the benefits of bass reflex and horn- loaded systems in a compact, sturdy housing covered with robust black laquer. The 56 Bit DSP manages limiters and delays for flawless system processing.
DVA KS20 is the perfect low-end complement for larger DVA K5 systems and can be used vertically in groundstacked configurations thanks to the DRK-20/10 pickpoints on top.
Technical Data:
Speaker Type Active Bassreflex-Horn loaded Subwoofer
Acoustical data
Frequency Response [- 10 dB] 41 Hz - 120 Hz
Max SPL 138 dB
Directivity Omnidirectional
LF 2x18 "
Voice Coil LF 4 "
Amplifier
Amp Technology Digipro® G3
Amp Class Class D
RMS Power 1800 W
Peak Power 3600 W
Cooling Convection
Power Supply 1800 W SMPS with auto range PSU
Processor
Controller DSP 56 Bit
AD/DA Converter 24 Bit /48 Hz
System Presets X-Over, Delay
Limiter Dual Active Multiband RMS, Peak, Thermal
Crossover Frequency LF-HF 90, 120 Hz (selectable)
Slope LF-HF 24 dB/Octave
Input
Input Selection 2x XLR Balanced
Output Selection 2x XLR Balanced
Power Socket 1x PowerCON in + 1x PowerCON Out
Controls
1 x Input Sensitivity Rotary Switch
1 x Setup Rotary Encoder (delay up to 4.5 ms on-board)
1 x Polarity Inversion Switch
1 x X-over Frequency Switch (90 Hz, 120 Hz)
1 x Output mode Switch (Link- X-Over)
1 x Setup Rotary Encoder (delay up to 4.5 ms on-board)
1 x Polarity Inversion Switch
1 x X-over Frequency Switch (90 Hz, 120 Hz)
1 x Output mode Switch (Link- X-Over)
Mechanics
Housing Plywood
Handles 3x Per Side
Rigging Points 2x Pick Points on top to fix
DRK10/20 rigging frames
DRK10/20 rigging frames
Pole Mount 1 x M20 on top
Width 1100 mm (43.31 in)
Height 580 mm (22.83 in)
Depth 720 mm (28.53 in)
Weight 84 kg (185.19 lbs)
