Omnitronic Em-260B Entertainment Mixer

£150.20
£186.00
£150.20
6-channel microphone/line mixer
Vendor: Omnitronic
SKU: 154-10007076
Icon In Stock In Stock
Icon Delivery Time

Description
Mixer for microphone and line sourcesThe perfect tool for your karaoke party: With the Omnitronic EM-260B Entertainment Mixer you mix 3 microphone and 3 line sources to one stereo output - in an very simple way. Installing the mixer is easy as well, thanks to the small dimensions you are flexible.Design clearly arrangedEven if you are a beginner, you can operate the mixer very easily. As it is clearly structured, you won't get lost. Each channel has a clip LED. The microphone inputs show optional 12 V phantom power. The unit is perfectly suited for bar, restaurant or club house installation.Effects an recording sessionsWith the FX send/return (with FX level control) you can cut in effects to support your voice. Record singing sessions by using the record output.

6-channel microphone/line mixer

  • 6 inputs (3 x mic/line and 3 x line) for mixing to 1 stereo output
  • Ideal e.g. for karaoke when microphones need to mixed with CDs
  • 3 mono input channels mic/line (XLR, bal.), switchable
  • 3 stereo line input channels (RCA)
  • Clip LED for each microphone channel
  • Each microphone input with optional 12 V phantom power
  • FX send/return with FX level control
  • Stereo master out (6.3 mm jack) with 2-band equalizer (highs and lows) and level control
  • Stereo record output (RCA)
  • (19") 48.3 cm rack installation 1 U


Power supply: 115/230 V AC, 50/60 Hz
Power consumption: 35 W
Protection class: Class I
Power connection: Mains input IEC connector (M) mounting version Power supply cord with safety plug (provided)
Frequency range: 20 - 20000 Hz
Phantom power: 12 V DC
Housing color: Black
Control elements: Phantom power switch, power switch, FX send/returne control
Status LED: Power, clip
Connections: Input: 3 x mic/line via 3-pin XLR
Input: 3 x line via stereo RCA
Input: 2 x FX via 6.3 mm jack socket (mono) mounting version
Output: 1 x rec. via stereo RCA
Output: 2 x master via 6.3 mm jack socket (mono) mounting version
Output: 1 x FX via 6.3 mm jack socket (stereo) mounting version
Chanals: Input chanel: 3 x stereo via RCA, channel control via Rotary knob, 2-band tone control EQ 100Hz/10kHz
Microphon chanal: 3 x mono with Mic-line switch via XLR, channel control via Rotary knob
Master output: 1 x stereo via Plug 6,3mm/3,5mm (Jack), channel control via Rotary knob
Max. level: Input: Microphone +14 dB
Input: line +24 dB
Material: Metal
Color: Silver
Housing design: (19") 48.3 cm rack installation 1 U
Dimension: Width: 48.3 cm
Depth: 12.3 cm
Height: 4.45 cm
Weight: 2.20 kg
