EUROLITE LED BP-9 Panel RGBW+CW Beam Matrix LED Effect

Description

This compact LED fixture delivers a powerful beam matrix effect using nine precision lenses, each producing an ultra-narrow 2° beam from individually controllable RGBW LEDs. Designed for dynamic stage and event lighting, it allows intricate patterns and aerial effects to be created with high intensity and accuracy. Complementing the beam output, 72 cold white LEDs are arranged in four independently controllable segments, providing additional strobe and blinder effects for maximum visual impact.

Features

Nine individually controllable 12W RGBW beam LEDs for detailed beam effects
Ultra-narrow 2° beam angle for sharp, defined output
Beam matrix capability for complex patterns and movement effects
72 cold white LEDs for strobe and blinder effects
Four independently controllable strobe segments
Stepless colour mixing with foreground and background colour control
Integrated beam and strobe effects
Nine built-in show programs for stand-alone operation
Direct colour selection with 31 preset colours
Multiple control modes including DMX, stand-alone, master/slave, and sound-to-light
Selectable DMX channel modes for simple or advanced control
Flicker-free operation with high PWM frequency
Double bracket for flexible mounting options
Power linking capability for up to 8 units

Specifications

Power supply: 100–240 V AC, 50/60 Hz
Power consumption: 70 W
Protection class: Class I
Light source: 9 x 12 W RGBW LEDs and 72 x 0.5 W cold white LEDs
Beam angle: 2°
Flash rate: 0.8 – 20 Hz
DMX channels: 6, 12, or 43 selectable
DMX connections: 3-pin XLR input and output
Control modes: Stand-alone, sound-to-light, master/slave, DMX
Cooling: Single fan cooling system
PWM frequency: 7000 Hz
Lamp life: 50000 hours
Housing material: Metal
Colour: Black
Display: 4-digit 7-segment LED
Mounting: Double bracket with Ø12 mm mounting hole
Dimensions (W x D x H): 261 x 105 x 264 mm
Weight: 2.75 kg
Noise level: Class 3 (clearly perceptible noise)
