FBT HiMaxX 60 15 inch Passive Speaker, 700W @ 8 Ohms

Description
Passive Monitor 700W 8OHM – 129DB SPL With the new HiMaxX series, FBT establishes a reference point on the scenario of 12” and 15” enclosures in polypropylene for sound reinforcement, introducing performance and technical content of a standard unthinkable up until now. FBT HiMaxX takes its place alongside the FBTMaxX series, exalting all the technical features. The study of a new cabinet in polypropylene, the use of a switch mode power supply and high efficiency power amplifiers and the redesign of the loudspeakers were the activities of the FBT R&D team aimed at maximizing the power weight ratio. This series comprises three models; two 2-way full-range enclosures in polypropylene, HiMaxX 40 (12”+1”) and HiMaxX 60 (15’’+1.4”), plus a compact 18’’ bandpass SUB in birch plywood (HiMaxX 100Sa). Compact and light weight, HiMaxX brilliantly solve all the most demanding requests from buffs, musicians and professionals looking for powerful, versatile and very high quality loudspeaker enclosures. Ideal for live and sound reinforcement applications requiring ease of transport, they are also suited to fixed installations, thanks to the cabinets’ format and optional accessories. HiMaxx 60 is a passive 15" Mid-top cabinet that is 700w RMS @ 8ohm producing 129dB SPL The low frequency driver is a custom designed B&C neodymium driver with a 3" voicecoil and a 1.4" compression driver with a 2.5" voicecoil also manufactured by B&C Long Term Power: 350w Short Term Power: 1400w Recommended amplifer: 700w RMS Sensitivity: 99dB

Features
2-way, passive Bass- Reflex design
B&C custom designed 380 mm (15”) neodymium woofer with 75 mm (3”) voice coil
B&C 36 mm (1.4”) compression driver with 64 mm (2.5”) voice coil
90°H x 60°V constant directivity horn
4 x M10 anchoring points, 35 mm ø (1.38”) top-hat for speaker stand placement and wall bracket mount flange, 2 integrated carrying handles
Passive version, 700Wrms/8ohm recommended amplifier
Passive crossover filter featuring “soft-trip” circuitry to ensure full protection of LF woofer and HF driver
2 NL-4 Neutrik™ Speakon connectors


Specification
Configuration:2 Way
Frequency response:40Hz - 20kHz
Low frequency woofer:15" with 3" VC
High frequency driver:1.4" with 2.5" VC
Maximum SPL cont/peak:129 / 132 dB
Dispersion:90 x 60 (HxV)
Input impedance:8 ohm
Crossover frequency:1.3 kHz
Input connector:2x Speakon
Net Dimension (WxHxD):482 x 757 x 427mm / 19 x 29.8 x 16.8in
Net Weight:26kg / 57.3lb
Transport Dimension (WxHxD):520 x 867 x 600mm / 20.4 x 34.1 x 23.6in
Transport Weight:28.5kg / 62.8lb
