Futurelight WDS-CRMX 2.4 GHz Duo TX Wireless DMX Transceiver 19"

Description:

Wireless DMX system 2.4 GHz - two transceivers with CRMX unit in 19" housing

Transceiver, to be used as transmitter or receiver
Control via CRMX by LumenRadio; W-DMX by wireless solution
Adaptive frequency hopping ensures interference-free operation in the 2.4 GHz band
Can receive and process up to 1024 DMX channels
Can transmit up to 1024 DMX channels
Operating range up to 600m with line-of-sight
Multicolored LED indicator
Mains input and output for power linking up to 8 units
(19") 48.3 cm rack installation 1 U

Specifications:

Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 3 W
IP classification: IP20
Protection class: Protection class I
Power connection: Mains input via P-Con (blue), mounting version power supply cord with safety plug
Power output: P-Con (gray), mounting version
Device fuse: T 1 A Fuse serviceable
DMX channels: Input 1024, Output 1024
DMX input: 2 x 3-pin XLR (M) mounting version, 2 x 5-pin XLR (M) mounting version
DMX output: 2 x 3-pin XLR (F) mounting version, 2 x 5-pin XLR (F) mounting version
Control: CRMX by LumenRadio; W-DMX by wireless solution
Status LED: DMX, level meter, power
Carrier frequency: 2,4 GHz
Modulation: GFSK
Antenna gain: 3 dBi
Parallel mode: Max. 10 transmitter
Range: Range up to 600m with line-of-sight
Color: Black
Housing design: (19") 48.3 cm rack installation 1 U
Dimensions: Length: 48,3 cm, Depth: 14,0 cm, Height: 44 cm
Weight: 1,33 kg
