Gemini UHF-216HL UHF Headset Dual Microphone Wireless Radio Mic System

The Gemini UHF-116 UHF Wireless Microphone System is designed to provide clear natural sound in any environment over longer distances. It includes the UHF-116 receiver and two UHF-16 HHM unidirectional dynamic pop resistant microphones for feedback rejection and high-SPL handling. The system has a range of up to 250 feet over 16 selectable frequencies to ensure optimal transmission with no interference. Providing unmatched performance and affordability this is an ideal wireless system for presentations, houses of worship, vocalists, and musicians.

High quality (single channel) UHF receiver with 250' range
16 operating frequencies between 854MHz and 864MHz
Phase Locked Loop (PLL) circuitry for increased reception
RF and AF LED indicators for monitoring incoming signal strength
Auto mute with squelch control and built-in noise reduction
Front panel output level control
Standard (1/4" 6.3mm jack) output
2x Combo headset/lavaliere (UHF-216HL)
Low battery LED indicator
Microphone On/Off switch

Specifications
Type of System UHF Frequency Agile
RF Carrier Frequency Range 682 - 698MHz
Maximum Operating Distance 250' (76.2m)
Overall Frequency Response 50Hz to 15kHz (+/- 3dB)
# Of Channels 16 Total

Receiver
Type of Receiver UHF-216
Type of Outputs 1/4" Phone
Headphone Monitoring No
Power Requirements 12-18VDC
Battery Type/Approx. Life AC Power Only
Antenna Type BNC-type, 50 ohms
Bias voltage 12VDC, 60mA, each

Transmitter
Polar Pattern Cardioid
Interchangeable Mic Heads No
Battery Type/Approx. Life Two 1.5V AA alkaline
Mute Switch Off/On Switch
RF Power 10mW (Max)

Dimensions
System: 170 x 30 x 103 mm
Transmitter: 66 x 97 x 25 mm

Weight
1.5 kg
