Hylec Inline TeeTube Connector 5-Pole 8-17mm TTK25BKSD

Hylec Inline TeeTube Connector 5-Pole 8-17mm TTK25BKSD

£25.99; £25.99
Unit price: per

Vendor: Hylec

SKU: 148-CONN1201

In Stock

Quantity:

I agree with

iFrame

DETAILS
DELIVERY AND RETURNS

Description:

TeeTube connectors can be used in many situations, for example inline connection of power and lighting cables.

Features:

Black TeeTube In-line 5 Pole Screw terminals end barrier contact
8mm to 17mm cable diameter
4mm max. conductor size
IP68 32A 450V rated
2 cable gland entries
Tough, robust construction with large cable range acceptance
Straight through, T splitter and Y splitter versions available
Dual terminal versions available for easy fitting and looping of conductors (2+2 and 3+3 poles)
Temperature rating of –40°C to +125°C

Specifications:

Cable entries: 2
Number of poles: 5
Terminal type: Screw – end barrier contact
Body material: PA66 / TPE
IP rating: IP68
Max. conductor size: 4mm²
Max. current: 32A
Max. voltage: 450V
Min. temperature rating: -40°C
Max. temperature rating: -40°C
Max. temperature rating: 125°C
Min. cable diameter: 8mm
Max. cable diameter: 17mm
