Laserworld ScanBar 10RGB 10000mW Diode Beam Laser Scanning

Description

The Laserworld ScanBar 10RGB is a white-light RGB laser with analogue modulation. It's controlled via four DMX profiles, making it easy to integrate into existing lighting setups. Each beam output features its own X/Y scan set with 25kpps at 8°. In addition to single-beam projection, the Laserworld ScanBar 10RGB offers > 100 pre-set patterns.

The Laserworld ScanBar 10RGB is equipped with RGB laser diode modules, with each RGB module delivering a power of 5 x 450 mW / 638 nm red, 5 x 600 mW / 525 nm green, and 5 x 950 mW / 450 nm blue. These power values are measured after the apertures.

Controlled via DMX profiles, the Laserworld ScanBar 10RGB is compatible with all current DMX controllers. This Laserworld ScanBar 10RGB can be effortlessly integrated into an existing lighting setup. It's a great visual effect for large events.

10 W guaranteed power
5 x RGB Diode Modules
5 x X/Y Scanners - 25kpps at 8°
Full colour mixing - analogue modulation
Extremely sharp beams - low divergence
Professional DMX with four different profiles

Guaranteed Power at aperture: 10'000 mW
Power Red: 5 x 450 mW / 638 nm
Power Green: 5 x 600 mW / 525 nm
Power Blue: 5 x 950 mW / 450 nm
Beam Specifications: 4 mm / 1.1 mrad
Scanner: 25kpps at 8°
Laser Source: Diode
Laser Class: 4
Operation Modes: DMX, stand-alone, master-slave
Basic Patterns: > 100
Power Supply: 85 V - 250 V AC, 50/60 Hz
Power Consumption: 150 W
Dimensions: 1000 x 152 x 105 mm (L x W x H)
Weight: 12 kg
