OMNITRONIC DJP-604 4-Channel Class D Amplifier
- £330.00
- £330.00
- Unit price
- per
iFrame
Description
4-channel class D amplifier in 9.5" housing, 4 x 150 W / 4 ohms, 4 x 80 W / 8 ohms
- Extremely low weight and height due to integrated switch mode power supply
- 4 level controls
- Inputs linkable for flexible configuration
- LEDs for clip and signal per channel
- Speaker switch-on delay
- Complete protection set
- Plug-in screw terminals for all connections
- Rugged steel chassis with aluminum front panel
- 9.5" desktop console
- Desktop console housing
- (19") 48.3 cm rack installation possible
| Power supply: | 230 V AC, 50 Hz |
| Power consumption: | 185 W 1/8 power |
| Output power: | 4 x 150 W RMS (4 ohms) 4 x 80 W RMS (8 ohms) |
| Power connection: | Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided) |
| Frequency range: | 20 - 20,000 Hz |
| S/N ratio: | >105 dB |
| Impedance: | Input 20 kOhm , bal. Input 10 kOhm , unbal. |
| Housing color: | Black |
| Circuitry: | Class D |
| Slew rate: | 20 V/µs |
| Damping factor: | >300 |
| Control elements: | Power switch, level control per channel |
| Controls: | Softstart short-circuit overheat overload VHF DC voltage |
| Status LED: | Power, signal, clip |
| Connections: | Input: line via 4 x screw terminal Output: speaker via 4 x screw terminal |
| Material: | Metal |
| Housing design: | Desktop console housing (19") 48.3 cm rack installation possible |
| Dimensions: | Width: 26,5 cm Depth: 21,4 cm Height: 4,4 cm |
| Weight: | 1,90 kg |
