Omnitronic EM-280 Entertainment Mixer

Description:

8-channel stereo mixer with 2 adjustable zone outputs, 19"

8 stereo line inputs, 2 stereo bus outputs
Balanced TRS jacks in each channel
1 additional XLR microphone input in channel 1
Nominal input level switchable between +4dBu and -10 dBV
Signal and overload indicators in each channel
4-digit stereo level meter for each bus output
Standard and mini headphone jacks
groundlift selector
(19") 48.3 cm rack installation 1 U

Specifications:

Power supply: 115/230 V AC, 50/60 Hz
Power consumption: 15 W
Protection class: Protection class I
Power connection: Power supply cord with safety plug (provided)
Frequency range: 20 - 20000 Hz
S/N ratio: >92 dB line
>65 dB Microphone
THD: Line <0,9 % at 1 kHz
Gain: Mic/line 18 dB
Housing color: Black
Connections: Input: line via 8 x 6.3-mm-jack (bal.)
Input: Microphone via 1 x 3-pin XLR
Output: master via 2 x 6.3-mm-jack (bal.)
Output: AUX via 1 x 6.3-mm-jack (bal.)
Housing design: (19") 48.3 cm rack installation 1 U
Dimensions:
Width: 48,3 cm
Depth: 28,0 cm
Height: 4,4 cm
Weight: 3,00 kg
