Wharfedale Pro DVP-AX215 Active Speaker 2x 15" Sound System 1140W

Description

DVP-AX215 is a dual 15″ two-way bi-amplified active loudspeaker from our DVP-AX Series — delivering powerful full-range performance with the extended low-frequency punch required for high-energy live sound and DJ applications.

Driven by Class D amplification delivering 570 W continuous (1140 W peak) power, DVP-AX215 combines dual custom Wharfedale Pro LF drivers with 2.5″ voice coils and a 1.75″ IRIS X HF compression driver to produce a commanding, full-bodied sound. With 90° x 60° dispersion and a maximum SPL of 133 dB @ 1 m, it ensures consistent coverage across large audience areas.

The integrated 6-position DSP allows quick adaptation to different acoustic environments and program types, providing reliable results with minimal setup time. Built for touring and installation, the enclosure delivers strength, portability, and performance confidence in demanding professional environments.

DVP-AX215 — for those who need more power, more presence, and more low-end authority.

System Type - Full-Range
Configuration 2-way
System Continuous Power 570 W
System Peak Power 1140 W
Max SPL @ 1m 133 dB
Freq Response (+/-3 dB) 45 Hz - 18 kHz
Freq Range (-10 dB) 40 Hz - 20 kHz

LF Driver Size 2 x 15"
LF Voice Coil Size 2.5"
LF Rated Impedance 2 x 8 Ω
LF Power (RE:AES2-2012) 2 x 350 W
HF Driver Type Compression Driver
HF Voice Coil Size 1.75″
HF Diaphragm Material Titanium
HF Exit Size 1″
HF Power (RE:AES2-2012) 40 W
HF Rated Impedance 8 Ω

Input Connector 2 x XLR & 2 x 1/4″ (Line/MIC)
Waveguide Type Elliptical
Enclosure Material MDF
Grille Material and Finish Steel Black
Finish Black Paint
Handles 2

Amplifier design Class D
DSP Controls Flat / Monitor / Speech / Bass / Punch / Live
Preset list Flat / Monitor / Speech / Bass / Punch / Live
Active loudspeaker Input Impedance Balanced: 20 K
Link Connector pin XLR
Input sensitivity 775 mv
Max input level 4 v
Line output Switchable LOOP/MIX Balanced Socket XLR
Main Power 220-240 V 50/60 Hz
Power Supply SMPS

Unpacked - Height (mm) 1058
Unpacked - Width Front (mm) 444.5
Unpacked - Width Rear (mm) 245.3
Unpacked - Depth (mm) 429
Weight - Nett (kg) 35.3
Weight - Gross (kg) 40.12
