Adastra RM120-WIFI 100V Mixer-Amplifier with WiFi App Control WIMM Spotify

Description

5-channel 19" rack-mountable mixer-amplifier, designed for commercial sound installations to power 100V line speakers or standard low impedance speakers. Input options include XLR (with switchable phantom power), mic/line jack, and RCA line. A switchable ‘voiceover’ feature automatically lowers the background music volume when a signal is detected via mic input 1, and rear panel 24V contacts can mute all except mic input 1 when triggered. A built-in audio player section can play mp3 files from a USB or stream audio wirelessly from Bluetooth®. A main feature of the RM-WIFI models is the ability to connect to a wired or wireless network for streaming audio from internet radio, playback services or even from a local NAS drive. Setup and control for this function is entirely via the WiiM Home­­ smart phone app with a choice of streaming services embedded. Outputs on screw terminal are via 4 switchable zones with a separate "always on" output for priority alert speakers.

Internet radio or audio streaming from WiFi or LAN connection
Free WiiM Home Player app for Android or iOS
USB player and Bluetooth receiver
4 switchable 100V outputs and 1 unswitched output
Optional 4–16 Ohm output
XLR input with switchable +20V phantom power
2 x mic/line inputs, 2 x RCA line inputs, 1 x RCA line output

Weight: 6.36 kg
Fuse: T3.15A
Output Power (RMS): 120 W
Power Supply: 170–264 Vac, 50 Hz (IEC)
DC Power: 24 Vdc (screw terminals)
Inputs: Mic XLR, 2 × mic/line jack, 2 × RCA line
Input Sensitivity (Mic 1, balanced): -53 dBV
Input Impedance (Mic 1): 5 kΩ
Input Sensitivity (Line, unbalanced): -15 dBV (-18.5 dBV line 5)
Input Impedance (Inputs 2–5): 1 kΩ
Line Output: RCA
Speaker Outputs: 4 switched + 1 non-switched, 100 V / 4–16 Ω / COM
Bluetooth Version: 5.0
Network Connection: RJ45 (LAN) or 2.4 GHz WiFi (802.11 b/g/n)
Remote Control: via WiiM Home app for iOS or Android
Controls: Mic 1, mic/line 2+3, line 4+5, bass, treble, master volume
Equaliser (Bass): 100 Hz ±10 dB
Equaliser (Treble): 10 kHz ±10 dB
Rear Panel Switches: Phantom, Vox, Mic/Line (2 and 3)
Phantom Power: +20 V (Mic 1 XLR, switchable)
Audio Source: Network audio, USB player, Bluetooth receiver
Emergency Control: 24 V contacts – mutes all except Mic 1 when triggered
THD: <1.0%
Dimensions: 433 × 320 × 88 mm
