Chauvet Intimidator Trio XD LED Moving Head Wash Beam

Description:

The Intimidator Trio XD is a powerful all-in-one LED moving head that combines beam, wash, and dynamic effect lighting into a single professional fixture. Designed for DJs, production companies, live venues, theatres, and event professionals, it delivers exceptional versatility while reducing the need for multiple lighting fixtures. Its lightweight carbon fibre composite housing offers excellent durability, corrosion resistance, and portability for both touring and permanent installations.

Featuring six high-output 270 W RGBW LEDs, the Intimidator Trio XD produces vibrant colour mixing, intense beams, smooth washes, and striking aerial effects. A motorised zoom allows seamless transitions between a tight 3° beam and a wide 22° wash, while the continuously rotating honeycomb effect adds eye-catching movement and texture to any light show. Built-in auto programmes with zone control make it easy to generate impressive, professional-looking displays with minimal programming.

The Intimidator Trio XD offers extensive control options including DMX, built-in D-Fi wireless DMX, RDM compatibility, and support for optional RFC and RFC-XL wireless remotes. Totem mode keeps beams focused on the dance floor during movement, while the full-colour LCD display allows users to configure, save, and recall scenes quickly. An onboard USB-C port also provides fast software updates, ensuring the fixture remains ready for the latest features and improvements.

Features

Professional LED moving head with beam, wash and effect functions

Six high-output 270 W RGBW LEDs

Motorised zoom from 3° to 22°

Continuously rotating honeycomb effect

Built-in D-Fi transceiver for wireless DMX and master/slave operation

Built-in RF receiver for optional RFC and RFC-XL wireless remotes

Carbon fibre composite housing for reduced weight and increased durability

Built-in Totem mode keeps beams focused on the dance floor

Built-in automatic programmes with zone control

Full-colour LCD display with scene save and recall

USB-C port for quick firmware updates

DMX, RDM and stand-alone operation

Smooth pan and tilt movement

Ideal for mobile DJs, theatres, live productions and event venues

Specifications

DMX channels: 16, 23 or 52

DMX connectors: 3-pin and 5-pin XLR

Pan: 540°

Tilt: 270°

Pan ranges: 180°, 360°, 540°

Tilt ranges: 90°, 180°, 270°

Light source: 6 x 270 W RGBW LEDs

LED life expectancy: Up to 50,000 hours

Zoom angle: 3° to 22°

Strobe rate: 0 to 20 Hz

Illuminance (3° beam): 124,299 lux @ 2 m

Illuminance (22° wash): 7,505 lux @ 2 m

Power supply: 100-240 V AC, 50/60 Hz (auto-ranging)

Power consumption: 348 W @ 120 V / 343 W @ 230 V

Current draw: 2.9 A @ 120 V / 1.5 A @ 230 V

Power linking: Up to 4 units @ 120 V, up to 8 units @ 230 V

Power cable length: 1.5 m

Control: DMX, RDM, built-in D-Fi wireless DMX, stand-alone, optional RFC and RFC-XL

Housing material: Carbon fibre composite

Approvals: CE, FCC, MET

Dimensions: 320 x 220 x 431 mm

Weight: 9.3 kg
