Citronic Q-PAD-8 Compact Mixer with USB/BT + Audio Interface

Description:

The Q-PAD-8 Compact Mixer is a versatile and feature-rich solution designed for live sound, home studios, podcasting, and mobile setups. Combining a traditional analogue mixer layout with modern digital connectivity, it offers powerful functionality in a compact, portable format.

Powered via USB-C, the Q-PAD-8 also features a dedicated USB-C audio interface, allowing direct recording and playback with a PC or laptop. With four mono input channels supporting both XLR (microphone) and 6.3mm jack (line/instrument), plus switchable +48V phantom power, it is fully equipped to handle dynamic and condenser microphones, as well as instruments.

Each channel features gain control along with bass and treble EQ for precise sound shaping. An AUX send allows routing to the built-in digital delay effects processor or to external equipment, providing added flexibility for both live and studio environments.

Two additional stereo channels support line-level inputs, while onboard media functionality includes a USB-A MP3/WMA player and Bluetooth connectivity for wireless audio streaming. Multiple output options — including XLR, jack, RCA, AUX, and headphone outputs — ensure seamless integration into any setup.

Features:

Compact multi-functional mixer for live, studio, and streaming applications
USB-C audio interface for direct recording and playback with PC or laptop
4 mono channels with XLR/jack inputs for mic, line, or instrument use
2 stereo line input channels for additional sources
Individually switchable +48V phantom power for condenser microphones
Built-in digital delay effect with AUX send control
USB-A media player for MP3/WMA playback from USB drive
Bluetooth receiver for wireless audio streaming
Bass and treble EQ on each channel for sound shaping
Multiple outputs including XLR, jack, RCA, AUX, and headphone

Specifications:

Power Supply:
5V DC, 3A (USB-C adaptor supplied)

USB Interface:
USB Type-C audio interface for PC

Inputs:
4 x mono XLR/jack combo inputs
2 x stereo L/R jack inputs

Outputs:
Main out L+R (XLR and jack)
Headphone output
AUX output
REC output L+R (RCA)

Audio Sources:
USB-A MP3/WMA player
Bluetooth receiver

Effects:
Adjustable digital delay

EQ:
Bass and Treble per channel

Phantom Power:
+48V (individually switchable)

Dimensions:
265 x 192 x 56 mm

Weight:
966 g
