RCF KX 515-A High-Performance Active Speaker 2000W Dual 5" RDNet

The KX 515-A is a compact and powerful 2-way point-source active speaker designed for both installed and portable sound systems where performance and footprint are key. With a maximum SPL of 127 dB and a wide 100° x 70° rotatable CMD horn, it ensures even coverage and detailed audio in a variety of settings. It integrates dual 5" neodymium woofers with a 2" voice coil and a 1.75" titanium dome high-frequency compression driver, delivering a robust and dynamic sound. Powered by dual Class-D amplifiers totaling 2000W and enhanced by onboard DSP with FiRPHASE and BMC processing, the KX 515-A delivers exceptional clarity and responsiveness. The speaker also includes RDNet networking for remote management and real-time monitoring, and its durable Baltic birch enclosure is available in black or white finishes to match any environment.

Features:
127 dB maximum SPL
Rotatable 100° x 70° CMD waveguide
2 x 5" neodymium woofers with 2" voice coils
1.75" titanium dome neodymium compression driver
2000W peak Class-D bi-amplification
Onboard DSP with FiRPHASE and BMC
Integrated RDNet network control
PowerCON TRUE1 TOP input/output connectors
Weather-resistant Baltic birch enclosure
Available in black or white finish
Quick-fit socket and integrated rigging points

Specifications:
Frequency Response: 70 Hz – 20 kHz
Max SPL @ 1m: 127 dB
Horizontal Coverage: 100°
Vertical Coverage: 70°
Compression Driver: 1 x 1.0", 1.75" v.c, neodymium
Woofer: 2 x 5.0", 2.0" v.c, neodymium
Crossover Frequency: 1200 Hz
Limiter: Fast Limiter
Protections: Excursion
Input Sensitivity: -2 dBu / +4 dBu
Input/Output Connectors: XLR, RDNet Ethercon
Total Power (Peak): 2000W
HF Power (Peak): 600W
LF Power (Peak): 1400W
Cooling: Convection
Power Connections: powerCON TRUE1 TOP IN/OUT
Cabinet Material: Baltic birch plywood
Grille: Steel with acoustic cloth
Mounting: 2x M10 top/bottom, 2x D.10 pins, Quick-fit pole mount
Handle: 2 (top and bottom)
Color: Black or White

Size / Weight:
Height: 456 mm
Width: 154 mm
Depth: 237.5 mm
Weight: 9.8 kg
