Clever Acoustics CS660LF 100V 8 ohms 8" 60W Ceiling Speaker Subwoofer

The CS660LF is a high-performance 8" ceiling subwoofer designed to extend the low-frequency response of background music and paging systems in commercial installations. With support for both 100V line and 8 ohms low impedance operation, it offers excellent flexibility across various audio setups. A rubber-edged woofer housed in a rigid metal enclosure delivers enhanced bass reproduction, while the rotary power tap selector allows precise power matching.

Ideal for use in restaurants, retail spaces, hospitality venues, and office environments, the CS660LF is flush-mounted with dog-ear clips for a secure and discreet installation. It includes a mounting template and supports up to 25mm panel thickness, making installation simple and consistent.

Features
3-year warranty
Rubber-edged woofer for reinforced low-end response
Supports 100V and 8 ohms operation
Rotary power tap selector for precise matching
Metal grille, ABS baffle, and metal enclosure for durability
Flush-mount dog-ear retaining clips for easy ceiling installation
Spring terminal connections for quick wiring
Supplied with installation template
Supports up to 25mm ceiling panel thickness

Specifications
Input: 100V / 8 ohms
Power Taps @ 100V: 3.8W, 7.5W, 15W, 30W, 60W
Power Taps @ 70V: 1.9W, 3.8W, 7.5W, 15W, 30W
Impedance: 2.6K ohms, 1.3K ohms, 670 ohms, 330 ohms, 165 ohms
Power Handling: 60W RMS @ 8 ohms
Sensitivity (1W/1m): 90dB (±3dB)
Max SPL (Rated W/1m): 106dB
Frequency Response: 50Hz – 180Hz
Driver: 8" LF
Connections: 2 x spring terminals
Cutout Diameter: 250mm
Mounting Depth: 180mm
Overall Dimensions: 195 x 275mmØ
Weight: 3.5kg
Colour: White grille with metal enclosure
