Description:
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 48 - 18,000 Hz
Max SPL: 128 dB
HF: 1" CD, 1.35" v.c
LF: 15", 2.5" v.c.
Dispersion: 90°x60°
Crossover Frequency: 1800 Hz (24 dB/oct.)
Amplifier
Amp Technology: Class D (LF) + Class AB (HF)
Power Peak (LF+HF): 800 W
Processor
Controls: 1x Volume, 1x Slide Switch Mic/Line
Indicators: Power On/Signal/Limiter LEDs
Controller: DSP 20/56 bit
AD/DA Converter: 24 bit/48 Hz
System Presets: Playback, Flat, Bass Boost, Wedge
Limiter: Peak, RMS, Thermal
Advanced DSP Functions: Linear Phase FIR Filters
Input
Signal Input: 1x Combo (XLR/Jack)
Mic/Line: 1x XLR/TRS
Bluetooth Input: 1x Bluetooth Receiver
Signal Output: 1x XLR Male (LINK/MIX)
Mechanics
Housing: Polypropylene
Handles: 3 (2 on side, 1 on top)
Angles Up: Monitor Use 45°
Pole Mount: 36 mm, double positioning
Width: 430 mm (16.92 in)
Height: 722 mm (28.44 in)
Depth: 402 mm (15.82 in)
Weight: 19.3 kg (42.54 lbs)
