Zenith LSP408 MKII 4 in 8 out Loudspeaker Processor

Description

Built around a powerful processor core, the Zenith LSP loudspeaker management systems offer a wide variety of features allowing the sound technician to adjust delay, dynamics, routing, crossover and EQ either from the easy to use interface on the front panel or via the Windows based PC editing suite. The processor is pre-loaded with a range of standard presets for basic systems including 2-way stereo, each of these maybe copied, edited and saved into user presets, or alternatively the sound technician may create and store their own. The user may backup or duplicate presets via the PC editing suite.

4 XLR inputs, 8 XLR outputs

24-bit DSP with high performance AD/DA converters

48kHz sampling rate

Input/output level control with -40dB to +12dB range in 0.1dB increments

4 band PEQ (parametric EQ) for each input and 5 band PEQ (parametric EQ) for each output - each EQ features parametric, low shelf 6dB, low shelf 12dB, high shelf 6dB and high shelf 12dB

PEQ frequency range: 19.7Hz thru 21.9kHz, gain range -30dB to +15dB, bandwidth: 0.017 to 4.750 octave

Output high pass and low pass filter, each filter has multiple slopes and types

Filter slopes: 12dB/Oct, 24dB/Oct,36dB/Oct, 48dB/Oct

Filter types: Butterworth, Bessel or Linkwitz-Riley

Up to 1 second of delay for each input and output, switchable and selectable

Compressor for each input and output with adjustable threshold, ratio, attack-time, release-time and knee type

Phase reverse for each input and output

Copy function allows settings to be copied between channels

Multi-channel parameters can be set simultaneously via the channel linking function

Jog wheel control for parameter adjustment

LCD display

7 segment LED level indicator for each input and output

User friendly and intuitive Windows PC software on USB flash drive

Power supply: 90~250V, AC 50/60Hz

Dimensions (H x W x D): 45 x 482 x 158mm

Weight: 2kg
